Bullet Design Catalog
Click on any design to view more details.
This expanding catalog contains designs that are already on file. As new designs are ordered, they are added here. You may choose from these designs, use one of these as a basis and specify modifications, or submit a completely custom drawing electronically or by regular mail.
These molds are designed to fit Lee six cavity handles. RCBS handles also fit, except some newer RCBS handles have reduced diameter screw holes in somewhat erratic locations. Minor modification to the RCBS handle may be required.
Mass produced bullet molds are designed with very conservative, minimal dimensions north of the crimp groove, so that they will chamber in the great variety of firearms out there. Best accuracy is usually accomplished with a much closer fit, tailored to a particular firearm. This catalog is a record of molds I've made. Be aware that due to their custom nature, many of these bullets are designed for a specific purpose or firearm, and won't necessarily fit or feed as drawn in all guns of that caliber.
Viewing designs of approximately .52 to .59 diameter
52-450LN
Basis for hollow base nose pour. Pin must be outsourced.
52-490B
Dreyse 1857 carbine with sabot
53-499M
Basis for hollow base nose pour. Hollowing pin must be outsourced
54-450P
Band diameter cannot exceed heel dia plus .06
54-460T
Heal diameter will be band dia - .062
54-470CN
Basis for hollow base nose pour. Hollowing pin must be outsourced
55-440FN
Basis for hollow base nose pour. Hollowing pin must be outsource
55-490R
Ring tail base dia limit .06 smaller than base band.
55-700D
Shank for a customers home made gas checks
55-760B
Shank for a customers home made gas checks
56-450BN
Basis for hollow base nose pour. Pin must be outsourced.
56-450S
Heeled for Ballard 56-56 Spencer
57-400H
Heeled design for Hall carbine
57-580PN
Basis for hollow base nose pour. Pin must be outsourced.
57-999P
Basis for hollow base nose pour. Hollowing pin must be outsourced
58-440ON
Basis for hollow base nose pour. Pin must be outsourced.
58-469GN
Basis for hollow base nose pour. Pin must be outsourced.
58-470B1
Basis for Hollow Base Nose Pour. Hollowing Pin Must be Outsourced
58-470B2
Basis for Hollow Point. Hollowing pin must be sourced elsewhere.
58-489CN
Basis for hollow base nose pour. Pin must be outsourced.
58-525M
Basis for hollow base nose pour. Pin must be outsourced.
58-575M
TC clone with shallower lube grooves
58-590BN
Basis for hollow base nose pour. Pin must be outsourced.
