Bullet Design Catalog
Click on any design to view more details.
This expanding catalog contains designs that are already on file. As new designs are ordered, they are added here. You may choose from these designs, use one of these as a basis and specify modifications, or submit a completely custom drawing electronically or by regular mail.
These molds are designed to fit Lee six cavity handles. RCBS handles also fit, except some newer RCBS handles have reduced diameter screw holes in somewhat erratic locations. Minor modification to the RCBS handle may be required.
Mass produced bullet molds are designed with very conservative, minimal dimensions north of the crimp groove, so that they will chamber in the great variety of firearms out there. Best accuracy is usually accomplished with a much closer fit, tailored to a particular firearm. This catalog is a record of molds I've made. Be aware that due to their custom nature, many of these bullets are designed for a specific purpose or firearm, and won't necessarily fit or feed as drawn in all guns of that caliber.
Viewing designs of approximately .59 to .73 diameter
60-520PN
Basis for hollow base nose pour. Pin must be outsourced.
62-451WN
Basis for hollow base nose pour. Pin must be outsourced.
62-600PN
Basis for hollow base nose pour. Pin must be outsourced.
62-907T
Shank for custom gas checks
63-950A
Basis for Hollow Base Nose Pour. Hollowing Pin Must be Outsourced
67-680AN
Basis for hollow base nose pour. Hollowing pin must be outsource
68-734F
Hole for HP pin cut almost clear through
69-679MN
Basis for hollow base nose pour. Pin must be outsourced.
69-6900
Basis for hollow base nose pour. Pin must be outsourced.
69-730L
Basis for hollow base nose pour. Hollowing pin must be outsourced
70-685K
Kammerlader Weight in pure lead
70-700C
Basis for hollow base nose pour. Pin must be outsourced.
70-711D
Dual diameter driving bands
70-944M
Hole for HP pin cut almost clear through
72-797E
Hole for HP pin cut almost clear through
72-960DN
Basis for hollow base nose pour. Hollowing pin must be outsourced
73-654E
Basis for hollow base nose pour. Hollowing pin must be outsourced
73-679SN
Basis for hollow base nose pour. Hollowing pin must be outsourced
73-690AN
Basis for hollow point. Hollowing pin must be outsourced.
73-730AN
Basis for hollow base nose pour. Hollowing pin must be outsource
73-730SN
Basis for hollow base nose pour. Pin must be outsourced.
73-735AN
Basis for hollow base nose pour. Hollowing pin must be outsource
73-740TN
Basis for hollow base nose pour. Hollowing pin must be outsourced
73-770SN
Basis for hollow base nose pour. Pin must be outsourced.
73-800CN
Basis for hollow base nose pour. Pin must be outsourced.
